Hacking Hardware Picofly - a HWFLY switch modchip

[Adran_Marit]

View attachment 358471

View attachment 358472
Cut the shell to make it match

nope, do not like



[binkinator]

View attachment 358471

View attachment 358472
Cut the shell to make it match

Bruh!



[tyw]

Bruh!

It's only 1 dollar in China with free postage



[binkinator]

It's only 1 dollar in China with free postage

Even better! Get well soon!



[Doodka]

View attachment 358471

View attachment 358472
Cut the shell to make it match

Well, you just killed cooling system with this mess



[binkinator]

Well, you just killed cooling system with this mess

I think there’s a clear case over the back that blocks the gaping hole that was chewed into the shell. Rub a little dirt on it and get back in there!



[tyw]

Well, you just killed cooling system with this mess

temperature is actually lower,but only on this model



[rcpd]

temperature is actually lower,but only on this model

I can't believe that. Also if you can solder to tiny points on the Switch and do it successfully, why couldn't you remove the USB-C port and buttons to make it fit? It will.



[qgywibczozfvvl]

View attachment 358471

View attachment 358472
Cut the shell to make it match

Wasn't there a way for internal power source ?

Do all switches require cut for pikofly ?,



[tyw]

I can't believe that. Also if you can solder to tiny points on the Switch and do it successfully, why couldn't you remove the USB-C port and buttons to make it fit? It will.

for update firmware，cuz It's not finished yet

Post automatically merged: Mar 11, 2023

Wasn't there a way for internal power source ?

Do all switches require cut for pikofly ?,

i think 2040-one can fit all models except ns lite



[qgywibczozfvvl]

for update firmware，cuz It's not finished yet

Post automatically merged: Mar 11, 2023

i think 2040-one can fit all models except ns lite

No like it not about fitting , more so about power source. Do you really need to drill square in case just to supply power to chip ?



[brecht6]

No like it not about fitting , more so about power source. Do you really need to drill square in case just to supply power to chip ?

I think the chip uses the power from the switch.



[qgywibczozfvvl]

View attachment 358471

View attachment 358472
Cut the shell to make it match

Explain ?



[binkinator]

Wasn't there a way for internal power source ?

Do all switches require cut for pikofly ?,

No. No it‘s not necessary to do that.

If you remove the usb and buttons and solder it in nicely it will fit just fine.

e: new Cellphone snaps are now available from the instant this plan was hatched!



[qgywibczozfvvl]

No. No it‘s not necessary to do that.

If you remove the usb and buttons and solder it in nicely it will fit just fine.

e: new Cellphone snaps are now available from the instant this plan was hatched!

View attachment 358492

USB and buttons of rpi 2040 right , RIGHT ?



[binkinator]

USB and buttons of rpi 2040 right , RIGHT ?

Of course. Please don’t remove USB and buttons from your Switch. This kills the Switch.



[qgywibczozfvvl]

Of course. Please don’t remove USB and buttons from your Switch. This kills the Switch.

Thanks



[halfashark]

View attachment 358471

View attachment 358472
Cut the shell to make it match

dude you need to censor gore and mark it nsfl
please don't encourage this wtf



[Warbeast]

Maybe it's best to keep the back cover off untill we have a working firmware that will hopefully allow for updating from the switch like with hwfly-nx toolbox
The rp2040-one looks much easier to hook up to usb



[nqtal]

Maybe in lite can remove cardreader and plug rp2040 on this place? Sacrifice headphone jack or make some cable.
