Hacking Discussion SX Core / Lite Battery drain

Emeraldu

Well-Known Member
Newcomer
Joined
Aug 14, 2019
Messages
56
Trophies
0
Age
31
XP
418
Country
Romania
I've got my Mariko Switch modded with SX Core about a month ago and since then I've noticed that the battery depletes even when the console is switched OFF (not in standby).
It will lose about 7% in 2-3 days (I must test again for exact numbers).
When on standby it will drain even faster, and that's normal, but when fully off, I wonder if it's the chip that is draining the battery. I mean it should be 100% after a few days.
Right ?

D

Deleted User

Guest
If the power is OFF then there is nothing for the SX Core to draw power from. Batteries just degrade over time.


Dust2dust

Well-Known Member
Member
Joined
Jun 17, 2010
Messages
1,612
Trophies
1
XP
2,444
Country
Canada
If the power is OFF then there is nothing for the SX Core to draw power from. Batteries just degrade over time.
Talking about battery degradation, what is the best practice to keep it healthy as long as possible?
1. Draining the battery while playing until it totally depletes, then re-charging fully.
2. Re-charging anytime without consideration of the % of power left, like what people do when they dock the Switch after they're done playing in handheld mode.


Emeraldu

Well-Known Member
Newcomer
Joined
Aug 14, 2019
Messages
56
Trophies
0
Age
31
XP
418
Country
Romania
Yes but 7% in 2 days for a new Li-ion battery is too much (mybswitch is new, made in 2020)
Only Ni-MH batteries self discharge so fast.


Emeraldu

Well-Known Member
Newcomer
Joined
Aug 14, 2019
Messages
56
Trophies
0
Age
31
XP
418
Country
Romania
The battery is the original one. Don't they have like a serial number so you can approximate the manufacturing date ?

Last edited by Emeraldu,

Hayato213

( -_・) ︻デ═一' * (/❛o❛)/
Member
Joined
Dec 26, 2015
Messages
10,527
Trophies
1
Location
Vector Industry
XP
5,416
Country
United States
There is nothing to worry about unless it goes from 100% to 0% in few minutes, 7% drain in two days that is nothing, a battery would still drain even if the unit is completely shut off, you can leave a unit powered off for a few week and when you touch it agian it would be 0%.


pausuri

Well-Known Member
Member
Joined
Jul 15, 2018
Messages
105
Trophies
0
Age
38
XP
579
Country
United Kingdom
have you tried to reset the Switch back to factory settings and test the Switch? Nothing to lose I guess

Last edited by pausuri,

ghjfdtg

Well-Known Member
Member
Joined
Jul 13, 2014
Messages
823
Trophies
0
XP
1,875
Country
That high drain definitely isn't normal. Even my release Switch barely loses anything if powered off completely. 1 month of use won't wear the battery this much.


pausuri

Well-Known Member
Member
Joined
Jul 15, 2018
Messages
105
Trophies
0
Age
38
XP
579
Country
United Kingdom
That high drain definitely isn't normal. Even my release Switch barely loses anything if powered off completely. 1 month of use won't wear the battery this much.

Yeah, that battery drain is definitely odd, could be a software based issue and maybe the factory reset helps with that ...


hartleyshc

Well-Known Member
Member
Joined
Oct 2, 2008
Messages
442
Trophies
0
Age
39
Location
Gainesville, FL
XP
829
Country
United States
You're trusting arbitrary numbers.

It's nothing. It's just software assuming what the remaining battery life is. The modchip isn't draining anything as it only gets power when the system is powered on.

All battery readings are estimates. There's no this is without a doubt 97% battery life or whatever.

Not to mention, just like a cell phone, when your device is plugged into the wall, it's actually draining by as much as 10% and filling back up again, even though that percentage in the corner says 100% the entire time. I can only assume Nintendo is doing the same thing as it's common practice to do this and why you're not powering batteries at 100% constantly.

This is a non issue and there is absolutely nothing to worry about.

Sent from my ONEPLUS A6013 using Tapatalk


Modificatorul

Well-Known Member
Member
Joined
Oct 28, 2009
Messages
259
Trophies
0
XP
1,297
Country
Russia
Probably software does not display corect values.

if I remember correctly it took 3 hours to backup nand with your pny 512 card which eventually died completely, and was replaced by pny, and ended up using another microsd Lexar ? for backup another 1h.

Staying to long in sx os menu can create slight batery desync , maybe, not shore yet.

And i will do the discharge off batery to safe level to try to recalibrate.
"
CTCaer commented on 26 Apr 2019
What you need to do is to calibrate the percentage. so you need to do a
100% -> 0% (after HOS powers off drain the remaining via hekate to 3.2V) -> 100%. "

Except in this case i will use multimeter to see the vcc and stay in sx os meniu or
https://anonfiles.com/L3yepaA8o8/hekate_mariko_bin to watch the voltage

You can help by using it until the batery will deplete.
When you have time drop by.

Last edited by Modificatorul,
  • Like
Reactions: Emeraldu

LiveMChief

Well-Known Member
Newcomer
Joined
Apr 11, 2020
Messages
85
Trophies
0
Location
USA
XP
319
Country
United States
@Emeraldu is right, sx core/lite/sx os don't power off properly similar with auto rcm bug.

When you power off a v2 with sx core is still draining 0.003A(around), to overcome this you need to press again the power button and keep pressed 10sec until is powered off properly this time.

Thanks TX for this and for the weist of time debuging your crap.
Tested on core, v2 ,10.1.0 fw , 1.3 core fw, and 3.0.4 crap.

So this need to by reported i will not, thank you.

P.S.
Buldge on the back solved, i hope now you are 150% satisfied.
View attachment 220251
Very funny you post this when I noticed a battery draining issue on my Lite.

Last edited by LiveMChief,
  • Like
Reactions: Modificatorul

Emeraldu

Well-Known Member
Newcomer
Joined
Aug 14, 2019
Messages
56
Trophies
0
Age
31
XP
418
Country
Romania
Thank you Anonymous for the fix. It worked, and you are right, the SX OS never fully shuts down when you power off.
To do this even better, just after you give the command for the console to shut down, there will be a circle like this dsadasdas.jpg letting you know that the console is about to shut down.
When you see that circle, keep the power button pressed for 10 seconds. The console won't power on then off again, but will go straight into full shut down and won't drain any battery anymore.

There's a very little downside to this, the chip will take a bit more to glitch the Nvidia Tegra next time when you power on. Just a few seconds more.

Edit: Forget the circle trick. Not working properly. Just hard reset the console after you turn it off (keep the power button pressed for 10 seconds and the console will shut down in the middle of boot sequence)

Last edited by Emeraldu,

pausuri

Well-Known Member
Member
Joined
Jul 15, 2018
Messages
105
Trophies
0
Age
38
XP
579
Country
United Kingdom
That’s really interesting, just to clarify:

You’re saying that when the spinning icon comes up after switching off the Switch from the menu we have to press down the power button for 10 seconds to fully power off the device and to avoid the modchip to draw energy when the Switch is off?
Is that correct ?


Last edited by pausuri,

Emeraldu

Well-Known Member
Newcomer
Joined
Aug 14, 2019
Messages
56
Trophies
0
Age
31
XP
418
Country
Romania
That’s really interesting, just to clarify:

You’re saying that when the spinning icon comes up after switching off the Switch from the menu we have to press down the power button for 10 seconds to fully power off the device and to avoid the modchip to draw energy when the Switch is off?
Is that correct ?



Correct. This is the only way. If you miss the circle and press like 2 seconds after, then the console will restart (turn on then turn back off during the boot process and still won't drain battery but nobody wants to risk a corrupt sdCard)

The modchip isn't draining the battery. The Nvidia Tegra SoC is draining.

Last edited by Emeraldu,
  • Like
Reactions: pausuri
