1. Cai0

    Cai0 Newbie
    Newcomer

    Joined:
    Aug 22, 2020
    Messages:
    6
    Country:
    Brazil
    So, i've made an other type of code that makes squares appear on the screen and this was the result:


    I've put the source code below:
    Code:
    #include <nds.h>
    #include <stdio.h>
    #include <vector>
    //#include <algorithm>

    class Square {
        public:
            int id;
            int x, y;
            u16* gfx;
            int color;
    };

    OamState* screen = &oamMain;
    std::vector<Square> all;

    void render(Square a);
    void add(std::vector<Square>*);
    void remove(std::vector<Square>*);

    int main(void) {

        //Init Engine
        videoSetMode(MODE_0_2D);
        vramSetBankA(VRAM_A_MAIN_SPRITE);
        consoleDemoInit();
        oamInit(screen, SpriteMapping_1D_128, false);
        //--

        while(1) {
        scanKeys();
        switch(keysDown()) {
            case KEY_A:
                add(&all);
                //Sub Screen Counter (works because of the consoleDemoInit() )
                consoleClear();
                iprintf("Squares counter: %d \n", all.size());
            break;
            case KEY_B:
                remove(&all);
                //Sub Screen Counter (works because of the consoleDemoInit() )
                consoleClear();
                iprintf("Squares counter: %d \n", all.size());
            break;
        }

        //Main Screen
        for(int i = 0; i < (int) all.size(); i++) {
            render(all[i]);
        }

        //Update
        swiWaitForVBlank();
        oamUpdate(screen);
        //--
        }
        return 0;
    }

    void remove(std::vector<Square>* all) {
        if(all->size() > 0) {
            all->pop_back();
        }
    }

    void add(std::vector<Square>* all) {
        const int MAX = 10;
        if(all->size() < MAX) {

            int _id = all->size() + 1;
            int _x = (rand() % SCREEN_WIDTH + 1);
            _x -= _x % 16;
            int _y = (rand() % SCREEN_HEIGHT + 1);
            _y -= _y % 16;
            u16* _gfx = oamAllocateGfx(&oamMain, SpriteSize_16x16, SpriteColorFormat_Bmp);
            int _color = ARGB16(1, rand() + 31, rand() + 31, rand() + 31);

            Square n = {_id, _x, _y, _gfx, _color};
            all->push_back(n);
        }
    }

    void render(Square a) {
        dmaFillHalfWords(a.color, a.gfx, 16*16*2);

        oamSet(
            &oamMain, // sub display
            a.id, // oam entry to set
            a.x, a.y, //position
            0, // priority
            15, // palette for 16 color sprite or alpha for bmp sprite
            SpriteSize_16x16,
            SpriteColorFormat_Bmp,
            a.gfx,
            0, // rotation
            false, // double the size of rotated sprites
            false, // don't hide the sprite
            false, false, // vflip, hflip
            false // apply mosaic
        );
    }



    I think is something related to the 'swiWaitForVBlank()', because at the squares will be fulled in colors after some updates, and each of the stripes that appears on each of the squares are of the same color.
    Just thinking here but not sure. I'm new to this stuff.

  2. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    That would make sense, if the square isn't filled up before the screen blanks, it will not be fully displayed. You wouldn't normally see that problem as sprites are usually pre-made rather than generated assets. You could achieve the same effect by making a square sprite with any color and adjust it by adjusting its palette.

    Coto likes this.
  3. Cai0

    Cai0 Newbie
    Newcomer

    Joined:
    Aug 22, 2020
    Messages:
    6
    Country:
    Brazil
    Yeah, i'm afraid that because of the way this turned out, this could be an sign of some kind of bug that i can't solve when i'll jump to sprites, i'm expecting something like broken sprites in the worst case... Anyway, i will jump to the sprite examples of libnds and hope that this will not be such a big deal to handle.

  4. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    I wouldn't worry too much - chances are that the system was trying to display the sprite before it was fully generated. You can avoid that issue in a variety of ways.

    Coto likes this.
  5. TaruDev_

    TaruDev_ Member
    Newcomer

    Joined:
    Nov 18, 2019
    Messages:
    28
    Country:
    Belgium
    hey I was wondering how would I get a anim sprite? Like how do I convert *given img* to a 16x16 sprite with 4 anim frames?


    Attached Files:

  6. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    Sprite animation is covered in the Tic Tac Toe example, and in more detail in the Sprites chapter. Basically you need to create a vertical strip of frames (16x64), each 16x16 block corresponding to sprites 0-3. I like to add an extra "blank" sprite as well for the purposes of hiding it, but you can use a hide sprite function instead to the same effect.

  7. TaruDev_

    TaruDev_ Member
    Newcomer

    Joined:
    Nov 18, 2019
    Messages:
    28
    Country:
    Belgium
    oh god I'm stupid, I was stuck for an hour on why it didn't work.
    the asset was 16bit instead of 256 color even tho I was loading it in as a 256.
    So it tried to read pallet data it did not have

    Foxi4 likes this.
  8. Rarz

    Rarz Newbie
    Newcomer

    Joined:
    Dec 10, 2020
    Messages:
    2
    Country:
    United Kingdom
    I wanted to ask about the link given here, I have clicked on it to download it but it seems to be broken. Is it an issue on my end or is the link not functioning anymore?

  9. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    The wizard has been dead for quite a while now, but no worries - DevkitPro and libnds still work exactly the same. The easiest way to compile nowadays is to simply use one of the templates that come with it. :)

    MrMcTiller likes this.
  10. TaruDev_

    TaruDev_ Member
    Newcomer

    Joined:
    Nov 18, 2019
    Messages:
    28
    Country:
    Belgium
    hmmpfh nf lib seems to have simple funtions for sound as well, but how do I get the .raw files? Is there a converter you would recommend?

  11. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    .raw is just that - raw, uncompressed audio. You can use any converter or editor to save in that format, just don't go crazy and use higher frequencies than the DS can handle, or effectively output, or you'll be wasting space for nothing. For larger files you can use streaming mp3's from NitroFS/FAT, or better yet, the maxmod library and tracker music which is a bit easier on the CPU.

  12. TaruDev_

    TaruDev_ Member
    Newcomer

    Joined:
    Nov 18, 2019
    Messages:
    28
    Country:
    Belgium
    oh didn't know that... thank you.

  13. IceyyColdSnipez
    This message by IceyyColdSnipez has been removed from public view by VinsCool, Jan 16, 2021, Reason: Spam.
    Jan 16, 2021
  14. JuanR4140

    JuanR4140 Newbie
    Newcomer

    Joined:
    Mar 29, 2021
    Messages:
    3
    Country:
    United States
    Hey, Hey, Hey! I'm the dude who messaged you recently! To me, it's still a miracle that you're still on gbatemp and even helping people out! ^^ It really means a lot, because as I've said there is little to no documentation on the internet for DS programming. I apologize if I posed the reply in the wrong section, as clicking the reply button brings me all the way to the bottom of the page and just enters the entire text of the section. I still don't know how to use this website properly, I'm new. Now, for the problem I'm facing. I followed your tutorial on sprites up to now, tried making a simple 16 x 16 256 color palette with magenta background sprite, passed it through GRIT, gave me the img and pal fie, I put them in nitrofiles and wrote this as the code:


    #include <gl2d.h>
    #include <nds.h>
    #include <nf_lib.h>
    #include <stdio.h>

    int main(int argc, char **argv){
    NF_Set2D(0, 0);
    NF_SetRootFolder("NITROFS");

    NF_InitSpriteBuffers();
    NF_InitSpriteSys(0);

    NF_LoadSpriteGfx("stickman", 0, 16, 16);
    NF_LoadSpritePal("stickman", 0);

    NF_VramSpriteGfx(0, 0, 0, false);
    NF_VramSpritePal(0, 0, 0);
    while(1) {
    NF_SpriteOamSet(0);
    swiWaitForVBlank();
    oamUpdate(&oamMain);
    }
    return 0;
    }


    the result on my physical DS is just the top screen to be black, displaying nothing, and the bottom screen to be white, displaying nothing as well. Desmume throws a "ROM header is invalid" warning, and just has a white screen.

    Any suggestions?

    Foxi4 likes this.
  15. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    The reason why the screens have different colours for you is because you've only initialised one of them - it's NF_Set2D(Screen, Mode). You need to use this function twice, one for each screen, screen 0 and screen 1.

    The reason why you can't see the sprite is because you haven't created it yet using
    NF_CreateSprite(Screen, Sprite ID, Graphics slot in VRAM, Palette slot in VRAM, Position X, Position Y).

    Keep in mind that you also have no background loaded on either screen, so depending on your sprite it may or may not be visible - I like to load a template background first so that I can see my loaded assets more clearly, you can replace it later.

    Not entirely sure why you're throwing an exception in Desmume, perhaps because the screens are not both initialised, but you have a good starting point now. I also suggest using NO$GBA for homebrew development - it's faster, more accurate and has better debug tools. Desmume is for commercial ROM's, it's not ideal for development.

    Have a closer read of the Tic-tac-toe example, it will show you everything there is to know about loading sprites into memory, spawning and destroying them.

    Hope this helps. :)

    JuanR4140 likes this.
  16. JuanR4140

    JuanR4140 Newbie
    Newcomer

    Joined:
    Mar 29, 2021
    Messages:
    3
    Country:
    United States
    Note to self, icon.bmp is mandatory. It gave me the error on ngba as well, turns out the icon.bmp had to be present. Now, it tells me "Sprite GFX 0 not found in VRAM Error code 111" What am I supposed to input for the graphics slot and palette slot in NF_CreateSprite()?

  17. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    You have to input whichever slot you loaded the sprite into. Make sure that you use the correct name for the sprite as well, otherwise it will fail to load.

    EDIT: Example, assuming you've loaded everything correctly:

    NF_CreateSprite(0, 0, 0, 0, 0);

    Will create a Sprite on Screen 0 with the ID number 0 using assets from VRAM loaded into slot 0 and the palette number 0 at the position of 0x0px. All the arguments are numbers, you just have to remember which one refers to what. :P

    Last edited by Foxi4, Mar 29, 2021
    JuanR4140 likes this.
  18. JuanR4140

    JuanR4140 Newbie
    Newcomer

    Joined:
    Mar 29, 2021
    Messages:
    3
    Country:
    United States
    IT WORKED! (I was doing NF_CreateSprite() before loadsprite and vramsprite)

    Thank you so so much. Can't believe you'd still be online answering people's questions! Displaying a simple sprite is just the beginning for me though. Thank you so much again, really means a lot! Documentation is vague and the fact you helped was incredible. Thank you!

    Foxi4 likes this.
  19. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    Cool, congrats! Have fun messing around with the DS - it's been a decade, but I still have fond memories of coding for it. Simpler days. :P I hope you'll enjoy the rest of the tutorial, just read it with a critical eye - it's been a loooong time and several forum migrations, so some of the code boxes are a tad "wonky". Double-check that what you're coding "makes sense" and is consistent with the actual tutorial, some of the examples didn't import quite right.

    In terms of execution order, things are simpler to debug if you think of the program as a long block diagram, each operation being one block. As you've discovered, you can only create things you have in memory already - it's easy if you're systematic, and you'll learn over time. :)

    Last edited by Foxi4, Mar 29, 2021
    JuanR4140 likes this.
  20. TaruDev_

    TaruDev_ Member
    Newcomer

    Joined:
    Nov 18, 2019
    Messages:
    28
    Country:
    Belgium
    any idea of how saves work? Havn't been able to find any examples or metions of it online.

  21. Foxi4

    OP Foxi4 Endless Trash
    Global Moderator

    Joined:
    Sep 13, 2009
    Messages:
    28,138
    Country:
    Poland
    Sure. The way I used to do it is that I prepared an array of variables that I want to save, then I saved them to a file using FAT/loaded from said file. Libfat works pretty much the same as NitroFS, with the added benefit of being able to access external files. You should be able to find a code reference for it. Once you're done with your saving/loading you can switch back to NitroFS and the program will continue as normal, I'm pretty sure NightFox already has libfat built-in.

    Last edited by Foxi4, Apr 2, 2021
