Homebrew Suggestion Flip screen vertically

[crossholo]

You know what would be a good tweak?
Something that allows the rotation of the screen so that the usb-c port can go up and the console can be put down and the joycons can still be used wirelessly.
Of course I do not know if any homebrew can do it with today's capabilities but, hey, just getting my idea out there for any developer who wants to try to make it.



[Taffy]

They have a fancy stand-thing for it, Nintendo does.

Your issue: the kickstand doesn't work upside-down tho



[Nyannurs]

They have a fancy stand-thing for it, Nintendo does.

Your issue: the kickstand doesn't work upside-down tho

just make a homebrew to reverse the kickstand too



[tabzer]

I'm hoping that there is a simple method to flip the screen display. I am trying to play pinball arcade, vertically, using flip grip, and can only play it upside down.



[hippy dave]

I'm hoping that there is a simple method to flip the screen display. I am trying to play pinball arcade, vertically, using flip grip, and can only play it upside down.

Might be worth pestering the game devs to support it officially.



[tabzer]

Might be worth pestering the game devs to support it officially.

I did write them a heartfelt message pleaing with them, but I'm not waiting. Right now I'm trying to figure out how a /title/ solution might work, and I'm learning how to decrypt ncas. I'm lost though. I made a thread.



[jigglypufffame]

The fact that it's 2021 almost 2022 and neither nintendo nor homebrewers have made it have auto rotation for upside down charging is quite alarming right now



[Hazerou]

It can be achieved using Cheats per Game.

Baldo The Guardian Owls v1.0.5
TID: 0100A75005E92000
BID: C39C99E807D11843

[60 FPS]
580F0000 03D53088
780F0000 00000F14
640F0000 00000000 00000001

[Default 30 FPS]
580F0000 03D53088
780F0000 00000F14
640F0000 00000000 00000002

[Flip The Screen Vertically]
580F0000 03D53088
780F0000 00000EF4
640F0000 00000000 00000003

[Revert Screen Flip]
580F0000 03D53088
780F0000 00000EF4
640F0000 00000000 00000000


I'm just not sure if it will work the same way for other games though.

How to Find it?

It's basically Minus 0x20 from FPS Code found using Method #2 & #3

Tutorial to find the FPS Code;
https://gbatemp.net/threads/tutorial-how-to-search-the-fps-codes-using-edizon-se.586786/post-9438830



[tabzer]

It can be achieved using Cheats per Game.

View attachment 283738

Baldo The Guardian Owls v1.0.5
TID: 0100A75005E92000
BID: C39C99E807D11843

[60 FPS]
580F0000 03D53088
780F0000 00000F14
640F0000 00000000 00000001

[Default 30 FPS]
580F0000 03D53088
780F0000 00000F14
640F0000 00000000 00000002

[Flip The Screen Vertically]
580F0000 03D53088
780F0000 00000EF4
640F0000 00000000 00000003

[Revert Screen Flip]
580F0000 03D53088
780F0000 00000EF4
640F0000 00000000 00000000


I'm just not sure if it will work the same way for other games though.

How to Find it?

It's basically Minus 0x20 from FPS Code found using Method #2 & #3

Tutorial to find the FPS Code;
https://gbatemp.net/threads/tutorial-how-to-search-the-fps-codes-using-edizon-se.586786/post-9438830

Can you please help me find the screen flip for pinball arcade (to use flip grip)?? This is such an amazing work around. I had no idea that cheats could manipulate this level of presentation.



[Hazerou]

Can you please help me find the screen flip for pinball arcade (to use flip grip)?? This is such an amazing work around. I had no idea that cheats could manipulate this level of presentation.

Ok I'll try. But this is the last one. Because I'm too busy to fulfill Requests right now.



[tabzer]

Ok I'll try. But this is the last one. Because I'm too busy to fulfill Requests right now.

This would fulfill me so much. If there is a way I can help/repay you, please let me know.

Sadly I'm pretty dumb when it comes to this sort of thing.



[Jayro]

You know what else would be nice? Having MelonDS configurable to a single joycon while playing DS games vertically. (You'd still need to take the joycon off to use L and R, but that's the only annoyance I see)



[Hazerou]

This would fulfill me so much. If there is a way I can help/repay you, please let me know.

Sadly I'm pretty dumb when it comes to this sort of thing.

The Pinball Arcade v1.3
TID: 0100CD300880E000
BID: FADC5BB443B6D715

[Screen Orientation]
580F0000 141577E8
580F1000 00000168
780F0000 00000F04
610F0000 00000000 000000??



?? = Orientation
00 = Flip Vertically (Mirrored)
01 = Flip Vertically
02 = Default Orientation
03 = Flip Horizontally (Mirrored)
04 = Rotate Counter Clockwise (Mirrored)
05 = Rotate Counter Clockwise
06 = Rotate Clockwise
07 = Rotate Clockwise (Mirrored)

There's no need to pay. It's fun discovering this type of things though.

But if you want to help and support me build my Dream PC, join our Discord and do or just don't. It's ok.



[hippy dave]

Really interesting find, nice work!



[tabzer]

The Pinball Arcade v1.3
TID: 0100CD300880E000
BID: FADC5BB443B6D715

[Screen Orientation]
580F0000 141577E8
580F1000 00000168
780F0000 00000F04
610F0000 00000000 000000??



?? = Orientation
00 = Flip Vertically (Mirrored)
01 = Flip Vertically
02 = Default Orientation
03 = Flip Horizontally (Mirrored)
04 = Rotate Counter Clockwise (Mirrored)
05 = Rotate Counter Clockwise
06 = Rotate Clockwise
07 = Rotate Clockwise (Mirrored)

There's no need to pay. It's fun discovering this type of things though.

But if you want to help and support me build my Dream PC, join our Discord and do or just don't. It's ok.

This is great! I've been hoping for a viable solution and this is definitely it! I'm going to play around with it some more later, but I am able to verify that it works (01 option).



[scenicend]

The Pinball Arcade v1.3
TID: 0100CD300880E000
BID: FADC5BB443B6D715

[Screen Orientation]
580F0000 141577E8
580F1000 00000168
780F0000 00000F04
610F0000 00000000 000000??



?? = Orientation
00 = Flip Vertically (Mirrored)
01 = Flip Vertically
02 = Default Orientation
03 = Flip Horizontally (Mirrored)
04 = Rotate Counter Clockwise (Mirrored)
05 = Rotate Counter Clockwise
06 = Rotate Clockwise
07 = Rotate Clockwise (Mirrored)

There's no need to pay. It's fun discovering this type of things though.

Hi Hazerou!
I´m trying to follow the tutorials for rotate the screen in "Pinball Jam" but i can't get nothing... I don´t understand what means :

""How to Find it?
It's basically Minus 0x20 from FPS Code found using Method #2 & #3""

Can you help me with this? Thanks



[scenicend]

I've got IT!!!!

This makes screen orientation of Pinball Jam for Nintendo Switch compatible with the Flip Grip:

Pinball Jam
TID: 0100AD50167EC000
BID: A44E17749BAC250B

[Screen Orientation]
580F0000 02B130D8
780F0000 00000EF4
640F0000 00000000 00000003

PD: The game is pretty bad but I want to have some other pinball game apart from the typical ones (Fx3,Zaccaria,Pinball Arcade...) . The one i haven't been able to find is stern pinball.

Regards!



[Metoroid0]

This is great! I've been hoping for a viable solution and this is definitely it! I'm going to play around with it some more later, but I am able to verify that it works (01 option).

I tried this for flipgrip but only the screen is flipped, the controlls are the same...reversed. How did you made it work??



[tabzer]

I tried this for flipgrip but only the screen is flipped, the controlls are the same...reversed. How did you made it work??

The code shouldn't change the controls. I'm not sure if I understand what you are experiencing.

Are you trying to change the controls or are you saying that the controls unexpectedly changed because of the cheat?



[Metoroid0]

The code shouldn't change the controls. I'm not sure if I understand what you are experiencing.

Are you trying to change the controls or are you saying that the controls unexpectedly changed because of the cheat?

Ignore what i said, it works fine, i made a mistake. Thanks for replying anyway!
