    Hello,
    I have a switch in 8.0 on which I dump the partition PRODINFO with Hekate, so I have the file prodinfo.bin.
    I wanted to know how to read it to recover the Device ID?
    I also have the keys.prod file if needed.
    Thank you.

  2. Chocola

    Chocola GBAtemp Meowgular
    Member

    Joined:
    Sep 18, 2018
    Messages:
    293
    Country:
    Korea, South
  3. templeofhylia

    templeofhylia homo supreme
    Member

    Joined:
    Sep 6, 2014
    Messages:
    143
    Country:
    Canada
    open PRODINFO in a hex editor like HxD, make sure the first 5 bytes are 43 41 4C 30 07 (the decoded text on the side should read CAL0.), so that you know it's been decrypted properly.
    offsets 0x546-555 contain the device ID. you can ignore the "NX" before that and only need those 16 digits.

    if you see a bunch of gibberish instead, then it wasn't decrypted properly/at all. you mentioned usage of Hekate but not HacDiskMount, so i'll assume you need to decrypt it. i copied these instructions with some changes from the readme file for SwitchSDtool.
    Download and use Lockpick_RCM in conjunction with Hekate CTCaer Mod to dump your NAND and keys if necessary (a NAND dump isn't really needed if you already have one, but i would at least recommend having an updated copy of your keys)
    Download HacDiskMount and use it to open up rawnand.bin
    Double click on PRODINFO
    Open up your keys document and copy in the first 32 characters from 'bis_key_00' to 'Crypto (Upper)', and the last 32 characters to 'Tweak (Lower)'
    (The same keys can be gathered from a biskey document)
    Click on 'Test', make sure the result says 'Entropy OK'
    Click on 'Browse' under 'Dump to file', and browse to where you want to save the file
    Click on 'Start'

    Last edited: May 17, 2019
    Agilato likes this.
  4. techx3
    This message by techx3 has been removed from public view by Quantumcat, Aug 22, 2019, Reason: Can't do that.
    Aug 22, 2019 Show
  5. Tigermean74

    Tigermean74 Member
    Newcomer

    Joined:
    Nov 2, 2019
    Messages:
    34
    Country:
    United Kingdom
    Hi, how do I get my rawnand.bin please?

  6. Danook28

    Danook28 Advanced Member
    Newcomer

    Joined:
    Jul 17, 2018
    Messages:
    68
    Country:
    Oman
    Why bisky save Little numbers in sd not same secren when do test not become green.?

    — Posts automatically merged - Please don't double post! —

    It give me error red msge (fail entropy)

  7. Markjim

    Markjim Newbie
    Newcomer

    Joined:
    Dec 9, 2019
    Messages:
    1
    Country:
    Philippines
    How to find the device id in the switch

  8. Danook28

    Danook28 Advanced Member
    Newcomer

    Joined:
    Jul 17, 2018
    Messages:
    68
    Country:
    Oman
    Yeah i try that im still look for fix...

  9. TotalJustice

    TotalJustice GBAtemp Fan
    Member

    Joined:
    Jan 28, 2017
    Messages:
    305
    Country:
    United Kingdom
    Hi, I created a simple app which displays the device ID, also has the option to dump it to a file. Hope this helps.

    https://github.com/ITotalJustice/NX-DeviceID-Viewer

    Agilato likes this.
  10. Danook28

    Danook28 Advanced Member
    Newcomer

    Joined:
    Jul 17, 2018
    Messages:
    68
    Country:
    Oman
    After that what help for????

  11. Danook28

    Danook28 Advanced Member
    Newcomer

    Joined:
    Jul 17, 2018
    Messages:
    68
    Country:
    Oman
    Is it away for back from incognito hide???

  12. TotalJustice

    TotalJustice GBAtemp Fan
    Member

    Joined:
    Jan 28, 2017
    Messages:
    305
    Country:
    United Kingdom
    I don’t really understand what you’re asking. Are you trying to restore your prodinfo?

  13. Danook28

    Danook28 Advanced Member
    Newcomer

    Joined:
    Jul 17, 2018
    Messages:
    68
    Country:
    Oman
    Yes bro.. Im sorry

    — Posts automatically merged - Please don't double post! —

    And i have psp E1004 black secreen after infinity flasher 6.61 get black screen any way for fix or go inside system by pc same hack disk amount

  14. Goffrier

    Goffrier GBAtemp Regular
    Member

    Joined:
    Dec 19, 2018
    Messages:
    177
    Country:
    United States
    totally unrelated also your psp is dead

  15. TotalJustice

    TotalJustice GBAtemp Fan
    Member

    Joined:
    Jan 28, 2017
    Messages:
    305
    Country:
    United Kingdom
    If you wiped your prodinfo using incognito and you don’t still have the backup that incognito make AND you don’t have a nand backup of you switch, then you have lost your prodinfo.

    As for your psp question, you’re better off asking in the psp section.

  16. Danook28

    Danook28 Advanced Member
    Newcomer

    Joined:
    Jul 17, 2018
    Messages:
    68
    Country:
    Oman
    Yes lost prodinfo...
