Help! N3DS problems after OTP's One Click Setup on 2.1

Discussion in '3DS - Homebrew Development and Emulators' started by eworm, Jul 24, 2016.

  1. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    I need help!

    I bought a brand new, fresh New 3DS XL which came with firmware version 9.6.0-24E and attempted to install arm9loaderhax + Luma3DS using the Plailect Guide.

    The entire process was going great, the only major hiccup being that the first downgrade to 9.2 was incomplete - I used my cartridge of Pokémon Super Mystery Dungeon to install an update (not wanting to go to 11.0, since that would ruin any hope of downgrading) and ended up on 10.2.0-20E. After trying again, the downgrade to 9.2 went without a hitch.

    I followed the remaining parts of the guide and it was going smoothly. But when it came to the downgrade to 2.1 (last steps of the tutorial's Part 4) an issue popped up. PlaiSys Updater claimed to have finished successfully and rebooted my console. Happy it went well, I initialized the OTPHelper from SysNAND and used the One Click Setup, the very last step in that part of the tutorial.

    And upon rebooting, I was greeted with a black screen.

    Booting without the microSD card did show the Home Menu properly, but putting it in after it booted didn't help at all. I had a mini panic attack, afraid I bricked my console for good (which still might be true), but I figured I might be able to recover with the solution to the previous issue. And I updated with Super Mystery Dungeon again.

    This solved the problem of booting without the microSD - however, I still receive black screen when trying to enter System Settings, so I'm not even able to confirm which firmware version I'm on (or which version the console thinks I'm on) or format the system.

    BrowserHax is out of the question, it wants me to update the system to use it, and my FreakyHax doesn't work for whatever reason, giving me an error and rebooting the system. Menuhax is no longer present and while I could try installing SuperMysteryDungeonHax or BaseHax from another HomeBrewable console, I don't know which firmware version to pick during installation.

    I found some claims that removing a 000002cc/d/e folder on the card might solve some problems, but I don't even have any folder like that - in any of my three (!) "scrambled letters and numbers" folders.

    Formatting the microSD and putting all the files back on didn't help anything either, though I didn't really expect it to. It was a rather desperate attempt.

    Is there any way to recover from this? Would launching Homebrew somehow allow me to recover the backup NANDs? According to Plailtect's guide, even updating to the newest firmware may brick my N3DS.

    Of course the final solution for me would be to return the console to the store and try to exchange it for another one. This one's brand new, they'd probably believe me if I claimed they accidentally sold me a faulty product. I don't want to do that though, not unless there are really no possible options left.

    Last edited by eworm, Jul 24, 2016
  2. grafate

    grafate GBAtemp Regular

    Member
    104
    7
    Jan 30, 2016
    United States
    Just a piece of advice that if you are going to return, update it normally and it should work properly. And when you return just say change of mind. That way the store gets a working console back.

    dimmidice likes this.
  3. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    Tried to install a New10.2.0-20E version of SuperMysteryHax on my cartridge and load it up on the console (which should be on that firmware, since that's the one the game installed previously), but it gives me an error yet again. Perhaps I just can't launch Homebrew at all.

    But a thought occurs - if I updated the console to the newest firmware, 11.0 and Homebrew worked on that one, would I be able to use OTPHelper to restore my NAND backups and regress to 9.2 or 2.1? Or would that be impossible even with NAND backups?

  4. The Real Jdbye

    The Real Jdbye Always Remember 30/07/08

    Member
    GBAtemp Patron
    The Real Jdbye is a Patron of GBAtemp and is helping us stay independent!

    Our Patreon
    12,512
    5,473
    Mar 17, 2010
    Norway
    Alola
    You should never update
    No, you can't restore a NAND backup on 11.0 unless you use the DSiWare method with fieldrunner.

  5. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    ^Does this mean my console's permanently bricked? I thought that since I managed to recover from the black screen issue, I'd be able to do something about the rest...
    Right now I'm mostly looking for ways to launch Homebrew to try to restore NANDs, but none of my entrypoints work...

  6. Resset

    Resset Advanced Member

    Newcomer
    51
    8
    Jan 19, 2016
    Poland
    Gliwice
    Can you boot the console to home menu or it just hangs on black screen? OTPHelper and similar apps will no work since there is no known kernel exploit for 11.0

  7. Swiftloke

    Swiftloke Hwaaaa!

    Member
    1,770
    1,525
    Jan 26, 2015
    United States
    Nowhere
  8. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    I was getting a black screen if I booted with the microSD card in, but not without it. After updating with Super Mystery Dungeon, I have the access to the Home Menu either way, but not to System Settings (black screen) or HomeBrew (error no matter which entrypoint I use).

    EDIT (above): Well, crap. What would be the possible recovery steps if I hadn't upgraded? If I was still on 2.1?

    Last edited by eworm, Jul 24, 2016
  9. Resset

    Resset Advanced Member

    Newcomer
    51
    8
    Jan 19, 2016
    Poland
    Gliwice
    Yeah... something like that.

    Do a hardmod and restore your NAND backup.

    Also why did you even think that update would fix your problem when in the guide is clearly written that FW update on n3ds will cause a brick?
    I think that your 3DS downgraded properly. You could delete Nintendo 3DS folder on the sd card and follow the guide.

  10. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    Well, hardmodding is not an option to me anyway. I would most definitely fry my console.

    So it's a confirmed brick, huh. Do You know whether the console would at least work properly if I updated to 11.0 using recovery mode? Or would it remain bricked? I'm probably going to end up returning the console to the shop, in which case I could probably just give them back a working one.

  11. Amapola62

    Amapola62 GBAtemp Advanced Fan

    Member
    938
    263
    Oct 25, 2015
    France
    I think it's normal to boot to a black screen when switching on with Sd in at 2.10-4...I had the same problem...I supposed it was normal to only be able to insert the Sd once the system had booted when at 2.1 so I porceded with the guide as normal.
    I simply continued with the steps :
    -I switched off my 3ds (I had tried to switch it on with sd in and got greated by the black screen)
    - Took the Sd card off the 3ds
    -Copied the recovery files to PC, and what needed to put in the SD card according to the guide in the sd card
    Switched on 3ds without sd card in
    Reinserted my SD card into my 3DS once the menus had loaded
    Went to http://dukesrg.github.io/2xrsa.html?arm11.bin on my 3DS
    Selected Full Install
    Proceded with the rest of the guide...

  12. Ev1lbl0w

    Ev1lbl0w GBAtemp Regular

    Member
    237
    55
    Dec 19, 2014
    You should have waited and be pacient before you updated with the game. I remember reading a lot of times when I did the guide that updating a N3DS in 2.1 firm would brick. You should have just waited, create a post of your problem, and don't mess with the console anymore.

    I hade done A9LH in three Old3DS, and in every one I had to take out the SD card before booting up the 2.1 system. I just inserted it later when booted and nothing bad happenned.

    But I think you still haven't tried this: can you boot in Recovery Mode? (Press A + R + L + Up on D-pad when you turn on the console) If yes, don't do anything more, just say if you can.

  13. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    The recovery mode does work.

  14. Ev1lbl0w

    Ev1lbl0w GBAtemp Regular

    Member
    237
    55
    Dec 19, 2014
    Then, I think System Settings isn't fully bricked. However I don't know how this works, so don't rely on me.

    If I were you, I would ask for support here: https://qchat.rizon.net/?channels=3dshacks&uio=d4

    If you're lucky, even Plailect can help you personally xD.

  15. Amapola62

    Amapola62 GBAtemp Advanced Fan

    Member
    938
    263
    Oct 25, 2015
    France
  16. Resset

    Resset Advanced Member

    Newcomer
    51
    8
    Jan 19, 2016
    Poland
    Gliwice
    Sometimes to get something we want we need to pay twice :) I have bricked my first n3ds and now I have a second n3ds with A9LH on it.

  17. Amapola62

    Amapola62 GBAtemp Advanced Fan

    Member
    938
    263
    Oct 25, 2015
    France
    Last edited by Amapola62, Jul 24, 2016
  18. eworm
    OP

    eworm GBAtemp Regular

    Member
    158
    80
    Jul 7, 2016
    Poland
    Big Thank You to Ev1lbl0w for looking for a solution for me on the IRC channel. I saw You, thanks for kinda defending me when I didn't even deserve it ^^'

    ^Can't follow that guide, since a) I don't have access to Homebrew and b) I am scared sh*tless of hardmodding and there's no hardmodder I could turn to.

    I guess I done goofed and will have to live with the consequences. Unbricking the console without hardmod seems completely impossible, so now the real question is whether to Recovery Mode Update or not before returning the console to the shop.

    Ev1lbl0w likes this.
  19. Ev1lbl0w

    Ev1lbl0w GBAtemp Regular

    Member
    237
    55
    Dec 19, 2014
  20. fikatr

    fikatr GBAtemp Advanced Fan

    Member
    880
    332
    Mar 29, 2016
    Turkey
    next to smea
    1. Select "One Click Setup" and confirm (you do not need to do an extra backup if asked, but you should make sure that you have copied the backup you made earlier to your computer as youwill need it later). This can take a while.
      (If this fails or gives you an error do NOT continue or you may BRICK; you should follow this troubleshooting guide)
    2. Cross your fingers
    3. Reboot
    4. If you get a black screen, boot with the SD card removed then reinsert when you see the home menu. If this fails, follow this troubleshooting guide
    really ???

    — Posts automatically merged - Please don't double post! —

    if you update nothing will change you are using o3ds firmware with n3ds

    — Posts automatically merged - Please don't double post! —

    its like putting a gamecube in a n64 housing and expecting it to play n64 games

    Last edited by fikatr, Jul 25, 2016
    TerryG likes this.
