Hardware 3DS Gamecube controller mod wiring

RubyOtaku

Well-Known Member
OP
Member
Joined
Sep 26, 2018
Messages
155
Trophies
0
Age
27
XP
486
Country
United Kingdom
I'm attempting a 3DS controller mod for someone. I have a board installed, however I still need to install adapters. First of all I wanted to do a gamecube adapter, however the wiring in this extension cable is different to what's in the guide. I'm self taught, I have a multimeter but need guidance
