View attachment 254034 View attachment 254035
View attachment 254036 View attachment 254037
View attachment 254038 View attachment 254039
View attachment 254040
Edit: A bit of a closer look at the cooling solution. Has some heft to it.
View attachment 254046
The heat sink was trimmed down from 80x80x20mm down to a +/- 60x60x20mm with "wings" for a hard mount, the plate was cut out of a 3mm thick copper sheet.
