@fledge68 I know that you want to take a break and I absolutely respect your decision. But for the future, can I request a little feature to add to WFL?
The ability to use a different background for each coverflow.
I'm working on an alternate version of Hakaisha's Rhapsodii theme and I was thinking that it would be great to make console-based backgrounds for emulators. Something like this:
Or maybe this feature can be achieved using sourceflow Tiers?

Last edited by Tetsuo Shima,
  • Like
Reactions: Hakaisha

fledge68

Well-Known Member
OP
Member
Joined
Jan 30, 2012
Messages
2,221
Trophies
1
XP
3,777
Country
United States
@fledge68 I know that you want to take a break and I absolutely respect your decision. But for the future, can I request a little feature to add to WFL?
The ability to use a different background for each coverflow.
I'm working on an alternate version of Hakaisha's Rhapsodii theme and I was thinking that it would be great to make console-based backgrounds for emulators. Something like this:
Or maybe this feature can be achieved using sourceflow Tiers?
noted and possible. had already considered it when i added backgrounds for sourceflow tiers.


suspendedhatch

Well-Known Member
Newcomer
Joined
Sep 5, 2018
Messages
46
Trophies
0
Age
42
XP
176
Country
United States
@Wiimpathy Yup. That worked. Thank you! And, sorry if I was unclear. I'm running WiiFlow Lite off my 2GB SD card, but have all my ROMs, backups, emuNand, etc is stored on a 2TB USB drive. However, my wiiflow_lite.ini was having all the cache go to the SD card instead of USB. I just copied over all the files, and then changed the folder mapping.

And sorry to be a total pain in the butt, but I've got another question. This one is likely a matter of preference, but is there a definitive list of the current most optimal emulators per console? Presently, I'm running the following:

  • NES: Retroarch-wii 1.7.5 w/ Nestopia core
  • SNES: Retroarch-wii 1.7.5 w/ SNES9x 2010 (FKA SNES9x Next) [Kinda torn between this and the regular SNES9x core.]
  • All Sega consoles (MS,SG-1000,MD/Genesis,GG,CD): GenPlus GX 1.7.5
  • GB/GBC: VBA Gx 2.3.7 [I've heard people recommend the Gambatte retroarch core, but I had major problems w/ compatibility]
  • GBA: Most recent stable mGBA build [I think this is universally heralded as the go-to GBA emulator over all the rest]
  • Neo-Geo, CPS1/CPS2: Retroarch-wii w/ Final Burn Alpha cores [As far as I know, the only real option for this?]
  • TGX16/PC Engine CD: This is one that I am totally lost on. There's too many options -- Hugo GX, WiiEngine, Retroarch cores, Wiimednafen (which I've never used at all)
Not even sure if this is the right place to pose this question, but I'd love some input.



--------------------- MERGED ---------------------------

Stick with RetroArch 1.73. Ever since I upgraded to 1.75, the savestate saving and loading has slowed to a crawl, often fatally crashing RetroArch.

Use RA for everything. As for cores, I believe mgba plays gb and gbc now.

SNES 9x core is the best choice except for romhacks. For those try snes9x_2005plus or 2010.

Last edited by suspendedhatch,
  • Like
Reactions: Hakaisha

dbz2k

Member
Newcomer
Joined
Nov 18, 2018
Messages
6
Trophies
0
Age
31
XP
70
Country
United States
I don't if I missed this in settings is there anyway to to use "Native Controllers" option from Nintendont?


EDIT: found the setting in the ini file. I just edited the file manually

Last edited by dbz2k,

JustMeDaFaq

Well-Known Member
Newcomer
Joined
Apr 17, 2017
Messages
49
Trophies
0
Age
30
XP
699
Country
Germany
I don't if I missed this in settings is there anyway to to use "Native Controllers" option from Nintendont?


EDIT: found the setting in the ini file. I just edited the file manually
The setting where removed, due to nintendont will autodetect it, as far as im concernce :)


thejaso

Well-Known Member
Newcomer
Joined
Jun 19, 2013
Messages
46
Trophies
0
Age
35
XP
358
Country
United States
Hello,
I love Wiiflow and was wondering about emunand running through it on vWii. Is there a guide how to setup everything to ren games through Emunand on Wiiflow Lite?


fledge68

Well-Known Member
OP
Member
Joined
Jan 30, 2012
Messages
2,221
Trophies
1
XP
3,777
Country
United States
for vwii use modmii to make an emunand and showmiiwads to add your games/channels.
note: this guide will also work for wii users. but wii users could just use wiiflow lites nand dump feature to make an emunand instead of using modmii. i don't know if wfl's nand dump will work for vwii.

get modmii here - https://sourceforge.net/projects/modmii/files/

use Complete Softmod Guide's method 1 to make the emunand with modmii - https://sites.google.com/site/completesg/how-to-use/sneek/setup/nand-dump
use CSG's tutorial to get and setup showmiiwads - https://sites.google.com/site/completesg/useful-tools/showmiiwads
use CSG's tutorial to add your game wads to your emunand - https://sites.google.com/site/completesg/useful-tools/showmiiwads/showmiinand

once your emunand is all setup:
your emunand should be in your modmii folder. if you made it for SD it will be in COPY_TO_SD/nands/pl_us or for USB in COPY_TO_USB/nands/pl_us
note: if you are not from the US then the pl_us will be pl_xx. xx for your country.

for vwii you will need to copy the folder pl_us and its contents to sd:/vwiinands/ or usb:/vwiinands
for wii you will need to copy the folder pl_us and its contents to sd:/nands/ or usb:/nands
note: i may change the vwiinands back to nands in the near future.

now run wiiflow lite.
goto main settings.
on page 1 choose game partitions
set emu nands partition to SD or USB for where your emunand was copied to.
back to config page 1
on page 1 choose nand emulation settings.
now choose your pl_us nand and set emulation to partial for now
now back to main screen.
wiiflow lite should show your games with blank covers. if not go to home menu and do reload cache.
goto main settings.
choose download covers and titles.
now select to download covers
go back to main screen when done and your games should have covers now. and your done.

in the future if you decide to add a game to your emunand you can use wiiflow lite to install it to your emu nand.
goto main settings.
on page 1 choose nand emulation settings.
goto page 2 and select install wad.
find your wad and select it
and choose your emunand and click go to install it.
go back to main screen. if it doesn't show goto home menu and do reload cache.

Last edited by fledge68,

Tetsuo Shima

Well-Known Member
Member
Joined
Oct 29, 2008
Messages
1,686
Trophies
1
Age
43
XP
3,546
Country
Italy
Hi Fledge, is there any way to move the banner area? Looking at the theme .ini file I see that you can change the TV frame position, but I can't find how to move the actual banner. Also, I was wondering if the game title can still be present when there is a banner, or if it just disappears. Thanks for your patience


fledge68

Well-Known Member
OP
Member
Joined
Jan 30, 2012
Messages
2,221
Trophies
1
XP
3,777
Country
United States
Hi Fledge, is there any way to move the banner area? Looking at the theme .ini file I see that you can change the TV frame position, but I can't find how to move the actual banner. Also, I was wondering if the game title can still be present when there is a banner, or if it just disappears. Thanks for your patience
No and no

  • Like
Reactions: Tetsuo Shima

suspendedhatch

Well-Known Member
Newcomer
Joined
Sep 5, 2018
Messages
46
Trophies
0
Age
42
XP
176
Country
United States
Everything's working except wii games off my sd card. I think it was working until recently. If I attempt to load a wii game it blinks the disc drive and resets back to the source menu.


Code:
Welcome to WiiFlow Lite 5.0.1!
This is the debug output.
Real Wii
AHBPROT disabled = yes
IOS58 v6176
patched isfs_permissions 1 times.
patched es_setuid 1 times.
patched es_identify 1 times.
patched hash_check 0 times.
patched new_hash_check 1 times.
Init ISFS
Found WiiFlow Save
Loading IOS Settings from wiiflow save
FAT Partition at sd: mounted.
using SD only, no need for USB mounting.
Running sound thread
Wiiflow boot.dol Location: sd:/apps/wiiflow_lite
Data Directory: sd:/wiiflow
Wii Games Directory: %s:/wbfs
Nintendont found
GameCube Games Directory: %s:/games
Loading cIOS map
Found d2x base 57 in slot 249
Found d2x base 57 in slot 250
Setting Wii games partition to: 0
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Creating Gamelist
Games found: 20
Coverflow started!
wiiflow main screen ready!
Coverflow stopped!
Creating Gamelist
Games found: 28
Coverflow started!
No game info!No game info!Coverflow stopped!
Creating Gamelist
Games found: 20
Coverflow started!
Saving IOS Settings to wiiflow save
Coverflow stopped!
Cleanup Coverflow
Stopping sound thread
Stopped sound thread
MEM1_freesize(): 8859632
MEM2_freesize(): 42635904

Welcome to WiiFlow Lite 5.0.1!
This is the debug output.
Real Wii
AHBPROT disabled = yes
IOS58 v6176
patched isfs_permissions 1 times.
patched es_setuid 1 times.
patched es_identify 1 times.
patched hash_check 0 times.
patched new_hash_check 1 times.
Init ISFS
Found WiiFlow Save
Loading IOS Settings from wiiflow save
Reloading into IOS 249 from 58...
Deinit ISFS
AHBPROT disabled after IOS Reload: yes
patched isfs_permissions 0 times.
Init ISFS
D2X IOS249[57] v8
FAT Partition at sd: mounted.
using SD only, no need for USB mounting.
Running sound thread
Wiiflow boot.dol Location: sd:/apps/wiiflow_lite
Data Directory: sd:/wiiflow
Wii Games Directory: %s:/wbfs
Nintendont found
GameCube Games Directory: %s:/games
Loading cIOS map
Found d2x base 57 in slot 249
Found d2x base 57 in slot 250
Setting Wii games partition to: 0
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Creating Gamelist
Games found: 20
Coverflow started!
wiiflow main screen ready!
Coverflow stopped!
Coverflow started!
Coverflow stopped!
Coverflow started!
Coverflow stopped!
Creating Gamelist
Games found: 20
Coverflow started!
Cleanup Coverflow
Coverflow stopped!
Stopping sound thread
Stopped sound thread
MEM1_freesize(): 8859632
MEM2_freesize(): 42587008

Welcome to WiiFlow Lite 5.0.1!
This is the debug output.
Real Wii
AHBPROT disabled = yes
IOS58 v6176
patched isfs_permissions 1 times.
patched es_setuid 1 times.
patched es_identify 1 times.
patched hash_check 0 times.
patched new_hash_check 1 times.
Init ISFS
Found WiiFlow Save
Loading IOS Settings from wiiflow save
Reloading into IOS 249 from 58...
Deinit ISFS
AHBPROT disabled after IOS Reload: yes
patched isfs_permissions 0 times.
Init ISFS
D2X IOS249[57] v8
FAT Partition at sd: mounted.
using SD only, no need for USB mounting.
Running sound thread
Wiiflow boot.dol Location: sd:/apps/wiiflow_lite
Data Directory: sd:/wiiflow
Wii Games Directory: %s:/wbfs
Nintendont found
GameCube Games Directory: %s:/games
Loading cIOS map
Found d2x base 57 in slot 249
Found d2x base 57 in slot 250
Setting Wii games partition to: 0
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Creating Gamelist
Games found: 20
Coverflow started!
wiiflow main screen ready!
Coverflow stopped!
Creating Gamelist
Games found: 20
Coverflow started!
Update Play log
Launching game CKBE88
Coverflow stopped!
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Game ID CKBE88 requested IOS 36.
User selected 250
Changed requested IOS to 250.
Reloading IOS into 250
Reloading into IOS 250 from 249...
FAT Partition at sd: unmounted.
Deinit ISFS
AHBPROT disabled after IOS Reload: yes
patched isfs_permissions 0 times.
Init ISFS
D2X IOS250[57] v10
FAT Partition at sd: mounted.
Return to channel WFLA using d2x succeeded.

Welcome to WiiFlow Lite 5.0.1!
This is the debug output.
Real Wii
AHBPROT disabled = yes
IOS58 v6176
patched isfs_permissions 1 times.
patched es_setuid 1 times.
patched es_identify 1 times.
patched hash_check 0 times.
patched new_hash_check 1 times.
Init ISFS
Found WiiFlow Save
Loading IOS Settings from wiiflow save
Reloading into IOS 249 from 58...
Deinit ISFS
AHBPROT disabled after IOS Reload: yes
patched isfs_permissions 0 times.
Init ISFS
D2X IOS249[57] v8
FAT Partition at sd: mounted.
using SD only, no need for USB mounting.
Running sound thread
Wiiflow boot.dol Location: sd:/apps/wiiflow_lite
Data Directory: sd:/wiiflow
Wii Games Directory: %s:/wbfs
Nintendont found
GameCube Games Directory: %s:/games
Loading cIOS map
Found d2x base 57 in slot 249
Found d2x base 57 in slot 250
Setting Wii games partition to: 0
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Emu NAND Full Path = sd:/nands/default
IOS Compatible NAND Path = /nands/default
Creating Gamelist
Games found: 20
Coverflow started!
wiiflow main screen ready!
Cleanup Coverflow
Coverflow stopped!
Stopping sound thread
Stopped sound thread
MEM1_freesize(): 8859632
MEM2_freesize(): 42592896

Last edited by suspendedhatch,

fledge68

Well-Known Member
OP
Member
Joined
Jan 30, 2012
Messages
2,221
Trophies
1
XP
3,777
Country
United States
@suspendedhatch
so it appears you are trying to launch a VC NDS game via an emunand on your SD card?

i see you used cIOS 250 which is base 57 and v10. i can't tell if it is beta52 or beta 53?
i would think you'd be better to use cIOS 249 because its v8. it might be more compatible with emu nands.


suspendedhatch

Well-Known Member
Newcomer
Joined
Sep 5, 2018
Messages
46
Trophies
0
Age
42
XP
176
Country
United States
It's probably better to focus on the first log. In the 2nd log I was trying everything. I installed v8, v10 b22 and 23, no difference between any of them for playing wii off the sd. The VC games still work fine, all my RetroArch systems work. GameCube works, but Wii crashes back to the source menu.

So it might be the emunand setting? I honestly don't fully understand the full implications of those settings. I get what they do superficially. I'll try messing with that.


suspendedhatch

Well-Known Member
Newcomer
Joined
Sep 5, 2018
Messages
46
Trophies
0
Age
42
XP
176
Country
United States
It's probably better to focus on the first log. In the 2nd log I was trying everything. I installed v8, v10 b22 and 23, no difference between any of them for playing wii off the sd. The VC games still work fine, all my RetroArch systems work. GameCube works, but Wii crashes back to the source menu.

So it might be the emunand setting? I honestly don't fully understand the full implications of those settings. I get what they do superficially. I'll try messing with that.


Changed "Saves NAND Emulation" to OFF fixed the problem.
Thanks!

  • Like
Reactions: fledge68

fledge68

Well-Known Member
OP
Member
Joined
Jan 30, 2012
Messages
2,221
Trophies
1
XP
3,777
Country
United States
@leseratte
question - doesn't wiimmfi work with animal crossing and other online games. not just mario kart?
with the new code will those games still work online?

edit: never mind. i get it now. private server patch is still there. but now theres mario kart wii game patch if private server is on and game is mario kart wii.

Last edited by fledge68,

suspendedhatch

Well-Known Member
Newcomer
Joined
Sep 5, 2018
Messages
46
Trophies
0
Age
42
XP
176
Country
United States
I didn't like how the aspect ratio on the NES button was squished so I decided to remake it.

I'm really grateful to the peeps in this thread always helping me out. I'm available to do any small graphic design jobs that you guys need for wiiflow lite so lmk.
I'd like to redo the channel animation...

Last edited by suspendedhatch,

sdoc96

Creaky Old Stiff Member
Member
Joined
Jan 10, 2007
Messages
338
Trophies
0
Location
Melbourne
XP
436
Country
Australia

thejaso

Well-Known Member
Newcomer
Joined
Jun 19, 2013
Messages
46
Trophies
0
Age
35
XP
358
Country
United States
for vwii use modmii to make an emunand and showmiiwads to add your games/channels.
note: this guide will also work for wii users. but wii users could just use wiiflow lites nand dump feature to make an emunand instead of using modmii. i don't know if wfl's nand dump will work for vwii.

get modmii here - https://sourceforge.net/projects/modmii/files/

use Complete Softmod Guide's method 1 to make the emunand with modmii - https://sites.google.com/site/completesg/how-to-use/sneek/setup/nand-dump
use CSG's tutorial to get and setup showmiiwads - https://sites.google.com/site/completesg/useful-tools/showmiiwads
use CSG's tutorial to add your game wads to your emunand - https://sites.google.com/site/completesg/useful-tools/showmiiwads/showmiinand

once your emunand is all setup:
your emunand should be in your modmii folder. if you made it for SD it will be in COPY_TO_SD/nands/pl_us or for USB in COPY_TO_USB/nands/pl_us
note: if you are not from the US then the pl_us will be pl_xx. xx for your country.

for vwii you will need to copy the folder pl_us and its contents to sd:/vwiinands/ or usb:/vwiinands
for wii you will need to copy the folder pl_us and its contents to sd:/nands/ or usb:/nands
note: i may change the vwiinands back to nands in the near future.

now run wiiflow lite.
goto main settings.
on page 1 choose game partitions
set emu nands partition to SD or USB for where your emunand was copied to.
back to config page 1
on page 1 choose nand emulation settings.
now choose your pl_us nand and set emulation to partial for now
now back to main screen.
wiiflow lite should show your games with blank covers. if not go to home menu and do reload cache.
goto main settings.
choose download covers and titles.
now select to download covers
go back to main screen when done and your games should have covers now. and your done.

in the future if you decide to add a game to your emunand you can use wiiflow lite to install it to your emu nand.
goto main settings.
on page 1 choose nand emulation settings.
goto page 2 and select install wad.
find your wad and select it
and choose your emunand and click go to install it.
go back to main screen. if it doesn't show goto home menu and do reload cache.

So I went through the process of creating a nand using this method described. when I went to load a wii game it sent me to the HBC. I then dumped my nand using the wiiflow lite app and same thing, boot to HBC. Not really sure what to do in order to get things up and running.


fledge68

Well-Known Member
OP
Member
Joined
Jan 30, 2012
Messages
2,221
Trophies
1
XP
3,777
Country
United States
So I went through the process of creating a nand using this method described. when I went to load a wii game it sent me to the HBC. I then dumped my nand using the wiiflow lite app and same thing, boot to HBC. Not really sure what to do in order to get things up and running.
wii game or wiiware/virtual console game on your emunand?

General chit-chat
Help Users
  • No one is chatting at the moment.
    The Real Jdbye @ The Real Jdbye: @Julie_Pilgrim and they don't wear out, so you never need to replace them, they don't take up...
